YESS-B-51.2V200Ah

LiFePO4 battery, more stable and safe .
Intelligent BMS equipped inside to maintain
the battery always work at best condition .
Max. charge and discharge current as 150A
which is specially designed for solar energy .
Excellent standby self-consumption as low as 4mA .

Automatically output cut off after 30days no
charge and discharge to ensure security ,
also can cut off output by manual operation

YESS-B-51.2V200Ah

Nominal property: Nominal capacity

200Ah; Nominal voltage

51.2/V

Mechanical properties: Terminal blocks

M8; Size L * W * H

1000*734*188/mm; Mass (approximately)

143kg

Electrical characteristics: Maximum continuous charging current

100A; Maximum instantaneous discharge current

100A 1Sec; Maximum continuous discharge current

100A; Float charging voltage

56.0V; Voltage usage range

44.8V to 58.4V

Operating conditions: Waterproof grade

IP20; safety standards

UN38.3.MSDS; Storage cycle

6 months at 25℃; Storage temperature

0 to 30℃; working temperature

Discharge -l0℃ to 50℃ Charge0℃ to 50℃; Cycle life (+25 ℃, 0.2C, 100% discharge depth)

>3000 Cycles
